Performance

 Lifting capacity

  kg/lbs

600 / 1320

 Bucket capacity

  m³

0.35

 Max. Lifting height to pin (Boom extended)

  mm/inch

2930 / 117

 Max. Lifting height to pin (Boom retracted)

  mm/inch

2270 / 91

 Weight without bucket

  Kg/lbs

1500 / 3300

 Engine

 Brand

  Changchai/Perkins/Yanmar

Rated power

kw/hp

18 / 25

Dimension

Max. length without bucket

mm/inch

2569 / 103

Max. width

mm/inch

970 / 39

Max. height to top of cabin

mm/inch

2070 / 83

Transmission

Hydrostatic

Speed

Km/h

Mile/h

0~10 / 0~6

Pump

Italian variable plunger pump

Motor

Orbital Motor

Driving

4 wheel drive

Turning angel

°

41.2

Min. turning radius (outer wheel)

mm/inch

2090 / 84

Min. ground clearance

mm/inch

184 / 7

Wheel Track

mm/inch

742 / 30

Wheelbase

mm/inch

1170 / 47

Tyre

23x8.50-12

Hydraulics

System pressure

Mpa/Psi

20 / 2900

Auxiliary Flow

L/min Gal/min

40 / 10

Capacity

Fuel tank

L/Gal

25 / 7

Oil tank

L/Gal

31 / 8
