Performance

 Lifting capacity

 kg/lbs

1000 / 2200

 Bucket capacity

 m³

0.5

 Max. Lifting height to pin (Boom extended)

 mm/inch

3207 / 128

 Max. Lifting height to pin (Boom retracted)

 mm/inch

2509 / 100

 Weight without bucket

 Kg/lbs

2000 / 4400

 Engine

 Brand

 Changchai/Yunnei/Perkins/Yanmar/Kohler/Cummins

Rated power

kw/hp

33 / 45

Dimension

Max. length without bucket

mm/inch

2860 / 114

Max. width

mm/inch

1300 / 52

Max. height to top of cabin

mm/inch

2260 / 90

Transmission

Hydrostatic

Speed

Km/h

Mile/h

0~12 / 0~7

Pump

Italian variable plunger pump

Motor

Orbital Motor

Driving

4 wheel drive

Turning angel

°

45

Min. turning radius (outer wheel)

mm/inch

2300 / 92

Min. ground clearance

mm/inch

268 / 11

Wheel Track

mm/inch

995 / 40

Wheelbase

mm/inch

1380 / 55

Tyre

26X12-12

Hydraulics

System pressure

Mpa/Psi

21 / 3045

Auxiliary Flow

L/min Gal/min

33.5*2 / 9*2

Capacity

Fuel tank

L/Gal

30 / 8

Oil tank

L/Gal

45 / 12
