Performance

 Lifting capacity

 kg/lbs

1500 / 3300

 Bucket capacity

 m³

0.8

 Max. Lifting height to pin (Boom extended)

 mm/inch

3515 / 141

 Max. Lifting height to pin (Boom retracted)

 mm/inch

2886 / 115

 Weight without bucket

 Kg/lbs

2460 / 5412

Engine

 Brand

 Changchai/Yunnei/Perkins/Yanmar/Kohler/Cummins

Rated power

kw/hp

36~44 / 50~60

Dimension

Max. length without bucket

mm/inch

3694 / 148

Max. width

mm/inch

1560 / 62

Max. height to top of cabin

mm/inch

2378 / 95

Transmission

Hydrostatic

Speed

Km/h

Mile/h

0~12~24 /

0~7~15

Pump

Italian variable plunger pump

Motor

Plunger Motor

Driving

4 wheel drive

Turning angel

°

45

Min. turning radius (outer wheel)

mm/inch

3200 / 128

Min. ground clearance

mm/inch

330 / 13

Wheel Track

mm/inch

1165 / 47

Wheelbase

mm/inch

1880 / 75

Tyre

31x15.5-15

Hydraulics

System pressure

Mpa/Psi

21 / 3045

Auxiliary Flow

L/min Gal/min

42*2 / 11*2

Capacity

Fuel tank

L/Gal

42 / 11

Oil tank

L/Gal

80 / 21
