Performance

 Lifting capacity

 kg/lbs

2000 / 4400

 Bucket capacity

 m³

1

 Max. Lifting height to pin (Boom extended)

 mm/inch

3746 / 150

 Max. Lifting height to pin (Boom retracted)

 mm/inch

2996 / 120

 Weight without bucket

 Kg/lbs

2540 / 5588

Engine

 Brand

 Changchai/Yunnei/Perkins/Yanmar/Kohler/Cummins

Rated power

kw/hp

50~55 / 68~75

Dimension

Max. length without bucket

mm/inch

3766 / 151

Max. width

mm/inch

1560 / 62

Max. height to top of cabin

mm/inch

2370 / 95

Transmission

Hydrostatic

Speed

Km/h

Mile/h

0~12~24

0~7~15

Pump

Italian variable plunger pump

Motor

Plunger Motor

Driving

4 wheel drive

Turning angel

°

45

Min. turning radius (outer wheel)

mm/inch

3224 / 129

Min. ground clearance

mm/inch

330 / 13

Wheel Track

mm/inch

1165 / 47

Wheelbase

mm/inch

1980 / 79

Tyre

31x15.5-15

Hydraulics

System pressure

Mpa/Psi

21 / 3045

Auxiliary Flow

L/min Gal/min

50*2 / 13*2

Capacity

Fuel tank

L/Gal

50 / 13

Oil tank

L/Gal

80 / 21
